Modular Design LV Withdraw Panel

The PN-GCK low voltage withdrawable switchgear is a state-of-the-art modular distribution device that complies with IEC 529 and DIN 40050 international standards. Its robust cabinet structure is constructed from galvanized C-profile steel with E=25mm module mounting holes, ensuring structural integrity and long-term durability even in demanding industrial environments. The switchgear employs high-quality electrical components from leading global brands, delivering stable electrical performance and extended service life. Its modular design allows for seamless customization, expansion, and upgrades, making it an ideal solution for both new construction projects and existing system retrofitting. Whether you need a central power distribution hub for a substation or a dedicated motor control system for a manufacturing plant, the PN-GCK switchgear can be tailored to meet your exact operational requirements.

Key Features & Customer Benefits

Standardized Modular Design: The fully modular construction provides maximum flexibility and scalability, enabling quick on-site installation, simplified future expansions, and cost-effective system upgrades without full replacement.

Drawer-Type Independent Units: Each functional unit can be safely withdrawn without interrupting the operation of other circuits, significantly reducing downtime during routine inspections, component replacement, and fault repairs.

Comprehensive Safety Protection: With protection ratings up to IP54 (optional), the switchgear effectively blocks dust ingress and splashing water from any direction. It is equipped with multiple built-in protection functions including short-circuit, overload, and leakage protection, safeguarding both your electrical system and on-site personnel.

Reliable Electrical Performance: Fitted with premium circuit breakers, contactors, and relays, the PN-GCK switchgear delivers consistent and stable power distribution, minimizing the risk of electrical failures and ensuring uninterrupted operation of critical equipment.

Intelligent Monitoring Capability: Supports advanced intelligent management systems that enable real-time monitoring of electrical parameters, automatic fault diagnosis, and proactive early warnings, enhancing overall system operational efficiency and reducing maintenance costs.

Space-Saving Compact Structure: The optimized cabinet design minimizes floor footprint, making it particularly suitable for installations where space is limited, such as data centers, commercial buildings, and compact industrial facilities.

Eco-Friendly Construction: Manufactured using environmentally friendly materials and energy-efficient designs, the switchgear reduces energy consumption and environmental impact, aligning with modern green industrial standards.

Technical Specifications

Cabinet Types & Configurations

Power Distribution Center (PC) Cabinet

Designed for main power distribution applications, the PC cabinet is compatible with Emax, MT, 3WN, AH, and ME series circuit breakers. It is available in multiple standard sizes to accommodate current ratings ranging from 630A to 4000A, making it suitable for various power distribution requirements.

Motor Control Center (MCC) Cabinet

Assembled with large and small interchangeable drawers, the MCC cabinet is optimized for controlling and protecting motors and other electrical loads. Each circuit is equipped with a high-breaking plastic-case circuit breaker or rotary load switch with fuse, ensuring reliable operation and easy maintenance.

Automatic Power Factor Compensation Cabinet

Equipped with manual, automatic, and remote power factor compensation devices, this cabinet improves power quality, reduces energy waste, and lowers electricity costs for industrial and commercial facilities.

Operating & Storage Conditions

Ambient air temperature: -5°C to +40°C (24-hour average temperature ≤ +35°C)

Relative humidity: ≤50% at +40°C; ≤90% at +20°C (occasional condensation is acceptable)

Altitude: ≤2000m above sea level

Storage temperature: -25°C to +55°C (short-term exposure up to +70°C for ≤24 hours is permitted)

Note: For applications on offshore oil drilling platforms and nuclear power plants, a separate technical agreement must be signed with our engineering team.

Applications

The PN-GCK low voltage withdrawable switchgear is widely deployed across diverse industries and facilities:

Power plants and substations

Industrial and mining enterprises

Commercial buildings and shopping malls

Data centers and IT infrastructure

Transportation hubs and public infrastructure projects

Why Choose PINO Electric?

As a professional low voltage distribution equipment manufacturer with over 15 years of industry experience, PINO Electric is committed to delivering high-quality, reliable products and exceptional customer service. We implement strict quality control processes throughout production, and all our products are CCC certified to meet international safety standards. We offer customized solutions tailored to your specific project requirements, competitive pricing, fast delivery times, and comprehensive after-sales technical support to ensure your complete satisfaction.

FAQ

What is the minimum order quantity for PN-GCK switchgear?

The minimum order quantity is 1 piece, making our switchgear suitable for both small-scale projects and large industrial installations.

Can I order the switchgear with IP54 protection?

Yes, IP54 protection is available as an optional upgrade. Please consult our technical team during the quotation process to specify your protection requirements.

What is the maximum rated current of the PN-GCK switchgear?

The maximum operating current of the PN-GCK switchgear is 3150A, while the main bus is rated for up to 6300A to support future system expansions.
