Distribution Epoxy Resin Cast 22kV 800kva Dry Type Transformer

Model:SC(B)10  Brand:Pino Electric  Rated Voltage:0.4-35kV  Rated Current:50-2500kVA  Rated Frequency:50/60HZ  Phase:3 phase  MOQ:1 piece  Rated Capacity:30-2500KVA

Overview

The SCB(10) dry-type transformer represents the forefront of electrical power conversion technologies, integrating epoxy resin casting techniques with superior insulation materials for unmatched efficiency, reliability, and safety.  This transformer caters to a broad spectrum of applications, from distribution networks to commercial and industrial facilities, particularly excelling in environments where environmental and fire safety standards are paramount.

Environmental Conditions

• Number of phases: 3 phases

• Frequency: 50Hz

• Insulation heat resistance grade: F class

• Winding average temperature rise: < 100K

• Local discharge: less than 5Pc

Product Features

• Efficiency and Energy Savings: Engineered with top-tier magnetic core materials and an innovative winding configuration, it dramatically cuts down on no-load and load losses, boosting energy efficiency.

• Environmental Stewardship: By eschewing liquid insulation mediums, it sidesteps potential leakage and pollution issues, underscoring its commitment to environmental preservation.

• Uncompromised Safety: Leveraging flame-retardant materials coupled with a sophisticated temperature control mechanism, it guarantees unwavering performance under even the most strenuous conditions.

• Whisper-Quiet Operation: Meticulous design and manufacturing practices ensure operation remains within minimal noise levels, enhancing ambient comfort.

• Durability and Low Maintenance: Its streamlined design, allied with premium materials and craftsmanship, promises extended service life and minimal upkeep.

• Versatile Application: Designed to perform in diverse settings and under varying load demands, it is equally adept at indoor and outdoor installations.

• Advanced Epoxy Resin Casting: This technique ensures uniform distribution of insulation material across windings, elevating insulation integrity and longevity.

• Elite Insulation Material: The use of H-class epoxy resin not only provides superior insulation but also withstands higher operational temperatures, reinforcing the transformer's durability and safety.

• Copper Strip Windings: This construction enhances mechanical robustness and thermal dissipation, enabling the transformer to endure sudden short-circuiting without damage.

• Efficient Heat Management: A well-conceived thermal dissipation system proficiently handles and expels operational heat, maintaining optimal internal conditions.
